What is antistatic coating?
What is antistatic coating?

Antistatic coating is a coating designated to repel static electricity by lowering the surface resistance while maintaining the non-stickiness and corrosion resistance that are typical properties of fluorinated coatings.
Thanks to these characteristics, antistatic coating can help prevent explosions, fires, and accidents in industrial sites caused by static electricity. In precision industries, it can minimize contamination on the equipment and facilities during the manufacturing process to prevent product loss.

Antistatic Powder Coating
Specification Product Name Color Processing Temperature Average Particle Diameter Recommended Coating Surface Resistance
ETFE SP-7239 Black 270~290℃ 60~80㎛ 300±100㎛ 10⁶~10⁸Ω
PFA SP-5138 Gray 380~400℃ 20~25㎛ 50~100㎛ 10⁵~10⁷Ω
SP-539TR Black 380~400℃ 20~25㎛ 30~50㎛ 10⁵~10⁷Ω
SP-539SS Black 380~400℃ 20~25㎛ 30~50㎛ 10⁷~10⁹Ω
SP-5239 Black 360~380℃ 30~35㎛ 250±50㎛ 10⁶~10⁸Ω
Antistatic Liquid Coating
Product Name Processing Conditions Color Surface Resistance
Metal Material Insulation Material
SS-4209BK-NT(EC) 230℃ 30 minutes Black 10⁴~10⁵Ω 10⁴~10⁵Ω
SS-4209BK-MS(EC) Black 10⁴~10⁵Ω 10⁷~10⁸Ω
SS-4209BK-FT (EC) Black 10⁷~10⁹Ω 10¹⁰~10¹³Ω
